ICON Dual Rate Overland rear coil springs for 2024-2026 Toyota Tacoma provide a modest increase in ground clearance on heavier Tacoma builds while also greatly enhancing on- and off-road performance, especially when used with ICON shocks and suspension components. Their dual rate coil design provides a softer ride rate with a firmer overload rate that combine to deliver on-road comfort with excellent load support, bottoming resistance, and superior off-road performance. These springs are designed to net .5" of rear lift over stock with approximately 600lbs of additional weight added to the rear, for a more aggressive stance and increased fender clearance for larger wheels and tires on more outfitted vehicles. Like all ICON coil springs, they feature a lifetime guarantee against sagging/breakage allow you to drive with confidence in knowing that you have the best suspension products available for the 2024-2026 Toyota Tacoma.
The ICON triple-rate coil springs provide a softer ride and droop rates with firmer overload rate that combine to deliver on-road comfort with excellent bottoming resistance and superior off-road performance.
APPLICATION NOTE #191: Advertised lift height ranges are for a vehicle with approx 600lbs of additional weight in rear. Increasing or decreasing weight of vehicle due to accessories will alter lift range.
Recommended Aftermarket Tires: 33" x 11.50" (Larger tires may fit but fender trimming and modifications will be required.)
APPLICATION NOTE #155: Requires recalibration of Advanced Driver Assistance Systems (ADAS) after install
APPLICATION NOTE #30: An adjustable track bar is recommended to realign the axle but not required.
Recommended Aftermarket Wheels: ICON Alloys - 17" x 8.5" with 5.75" Backspace / 25mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 18" x 9" with 6" Backspace / 25mm Offset
APPLICATION NOTE #164: Will not fit Tacoma submodels equipped with rear leaf springs
Significantly improves on- and off-road ride quality and performance over stock
.5" rear lift height over stock with 600lbs of additional weight in the rear
Dual rate rear coil springs with ICON-engineered ride and overload rates
ICON 2024+ Tacoma .5in Lift Overland Rear Coil Spring Kit
24-26 TACOMA .5" LIFT OVERLAND REAR COIL SPRING KIT
Dual stage powder coating for corrosion resistance
Lifetime guarantee against sagging/breakage
Factory Wheels & Tires Fitment: Yes
COIL SPRING KIT
Coil Spring Set
51215
